Braze Asteroids Deluxe Multigame Free Play and High Score Save Kit
We are not building anymore of the Braze Asteroids/Asteroids Deluxe/Lunar Lander kits. We have exhausted our parts inventory and POKEY inventory.
Good news is Scott Brasington is selling his kits again and going to make them open source! See all the details HERE
If you have any questions, you can contact Scott directly - email@example.com
The Asteroids Multigame and Asteroids Deluxe Multigame are add-on enhancement kits that extend your Atari Asteroids or Asteroids Deluxe game board to play all 3 games: Asteroids, Asteroids Deluxe, and Lunar Lander. As with all Braze Technologies multigames, these kits are loaded with features such as high score save, on-screen settings configuration, and enhanced diagnostic selftests. Switch between games at anytime by simply pressing both start buttons at the same time.
Lunar Lander Huh? how does that work? Check out the Lunar Lander info page for a detailed description of how Lunar Lander is mapped on to the Asteroids Multigame. Additionally there is a Multigame FAQ for commonly asked questions and instructions on how to use the multigame kit.
The Multigame kit comes in two models. One for Atari Asteroids boards and a different version for Atari Asteriods Deluxe boards. For detailed information select the model of the kit by clicking on corresponding image below.
The kit typically installs in less than 30 minutes on your Atari Asteroids board. Simply remove a two socketed chips, replace them with two new daughter cards provided in the kit. Then attach (solder) 2 wires from the daughter cards to your game board. Thats it! It is ready to go! No board modifications other than attaching the 2 wires.
Kit installs in minutes on your Atari Asteroids Deluxe boardset. No soldering or special skills needed. Simply remove a few socketed chips and plug in the kit. It doesn't get much simpler than this! See detailed Installation Guide and Trouble Shooting Guide.
Switch between games at any time by pressing and holding both start buttons at the same time. Game will instantly switch to the next game in the sequence. No additional switches are needed.
Asteroids extended scoring. This kit contains special code modifications derived from the Asteroids High Score Save Kit allowing scores up to 9,999,990 instead of the original 99,990. No more losing your high score when you roll over the 100K mark. See sample screen shots
The on-screen interactive setup menu provides access to configure game play settings separately for each of the games including resetting of the high score tables. No need to fiddle with DIP switches anymore.
Transfer your existing Asteroids high scores. If you currently own the Braze Technologies Asteroids High Score Save Kit. You can transfer the high scores from that kit to the multigame kit using a simple procedure of moving a single chip from one kit to the other. See importing Asteroids high scores.
Transfer your existing Asteroids Deluxe high scores. The Asteroids Deluxe multigame version of this kit will automatically import your existing high scores from the EAROM chip the very first time asteroids deluxe is played on the multigame.
Special high quality gold plated machined header pins on the daughter cards. Provides a perfect mate with your Asteroids sockets. High reliability and strength for a long lasting connection. Daughter cards snap firmly into place. See picture.
Top 10 high scores and initials for Asteroids and Asteroids Deluxe are remembered permanently, long after the game has been powered off. No batteries to replace ever.
Easy to clear out the high scores when desired. Simply put the game into testmode, follow the instructions to get into setup mode. From there, select the high score reset option for the desired game(s) and exit out.
Improved selftests and diagnostics including new sound tests, new input tests and enhanced memory diagnostics.
Asteroids software includes a new feature allowing the selection of EASY gameplay (original) versus HARD gameplay. This implementation is a result of merging the original Atari Asteroids software with a previously rare Atari Asteroids release. This later Asteroids release changed the game software in order to make the gameplay more difficult. The Asteroids Multigame allows selection of either difficulty level. See Asteroids harder gameplay details (jpg).
Atari released a 2nd version of Asteroids Deluxe which had easier gameplay (probably due to complaints). In that revision they added a DIP switch setting allowing selection of the original (hard) gameplay or the new (easy) version. This kit is based off the 2nd release and allows selection of EASY or HARD gameplay via the setup menu. See Asteroids Deluxe Revision 2 release (jpg).
Fixes the Asteroids "missing last letter on the 10th score" bug. There is a bug in the Atari REV2 code whereby every time you start a game, the last letter (initial) in the 10th score is erased. The modified software on this kit fixes that errata.
The Lunar Landing implementation on the multigame gives visual feedback on the screen when selecting the mission type.
|All 3 games have improved free play.|
Please see Install Guide for instructions and troubleshooting
Awesome, love this kit. So fun playing lunar lander. All games play awesome.
Oh yeah. Get it!
Easy install and works perfectly Fast shipping to Canada!
A must have for any Asteroids Cabinet.
Installed in my Asteroids Deluxe Cabaret in minutes. Thanks!!
Super fast shipping, great service, great kit
Super easy install. I had a small glitch (an issue with my original PCB, not the kit) that was identified and resolved with one email to high score saves. Fantastic kit and super service!
Easy to install and worked perfectly
Great option for your game
Ordered this and the Asteroids multi for my machines, great kit all the way around!
Awesome kit, works perfectly and always fast shipping!
Excellent customer service, fast delivery, great kit!
Does the Asteroids/Asteroids Deluxe multigame support cocktail cabinets?
Sure does! Few more details in the Install Guide.
Does the "Multigame Free Play and High Score Save Kit" support two player screen flipping on a cocktail cabinet? How is this enabled?
There is no setting for cocktail on the Multigame since the monitor has relays in it to send the signal in a cocktail cab to swap players. Same thing for Space Invaders…
I ordered a Asteroids Deluxe multi game kit a few weeks ago. Got it installed today into my AD cabaret machine... it seems lunar lander has a graphics glitch. The attract mode seems fine. Selecting mission is fine. Once I start a game, certain parts of the screen are extremely glitchy. Mostly in the lunar landscape and within the read outs at the top of screen (fuel, score, etc). All diagnostics checkout fine. Asteroids and Asteroids Deluxe are rock solid - graphics and gameplay are perfect. I even removed kit and went back to the original PCB configuration and AD played properly - no glitches. Upon reinstalling the kit, had the same result with glitchy graphics on LL only. I searched KLOV forum and came across a post about the same issue caused by a particular chip on some braze kits. Might this be possibly what I am experiencing?
Not at all, those eproms haven’t been used in years…
My suggestion is adjusting the X and Y pots on your original pcb to help with the weird refresh rate on LL. Find the balance with the other 2 games.
